MotorSim 2

MotorSim 2: Precision Performance Calculator for Land Vehicles
Advanced Physics-Based Simulation Engine for Automotive Engineering & Tuning

🛠️ Core Features – Full Vehicle Dynamics Modeling

MotorSim 2 delivers high-fidelity, real-world physics simulation grounded in classical mechanics, thermodynamics, and fluid dynamics. All calculations are based on measurable engineering principles, not approximations.

🔧 1. Engine Modeling (High-Resolution Power/Torque Curves)

• Input: Peak horsepower (HP) and torque (Nm), with full curve definition via user-defined RPM points (up to 20 data points)
• Advanced Features:
  • Polynomial interpolation between user-defined torque/power points
  • Inclusion of engine inertia and rotational mass effects
  • Realistic torque rise and fall characteristics
  • Redline RPM with power falloff modeling beyond peak
• Output: Instantaneous horsepower and torque at every RPM in real time

⚙️ 2. Drivetrain & Transmission Configuration

• Gearbox Settings:
  • Up to 10 selectable gears (manual or automatic)
  • User-defined gear ratios (including final drive and differential)
  • Optional: Launch control settings (torque management, clutch slip control)
• Shift Dynamics:
  • Adjustable shift duration (0.1–2.0 seconds)
  • Clutch engagement profiles (soft/standard/sport)
  • Gear-lag and inertia delay simulation
• Efficiency Modeling:
  • Transmission losses (mechanical efficiency: 92%–98% adjustable per gear)
  • Differential losses (including limited-slip torque bias ratio)

🚗 3. Vehicle Dynamics & Aerodynamics

• Mass & Inertia:
  • Total curb weight (kg): 800–4000 kg (adjustable by component)
  • Center of mass height and longitudinal bias
  • Rotational inertia (flywheel, wheels, driveshaft)
• Aerodynamics:
  • Drag coefficient (Cx): 0.25–1.0 (e.g., Formula 1 to SUV)
  • Frontal area (m²): 1.5–4.0
  • Downforce modeling (optional: lift coefficient vs. speed)
• Tire & Rolling Resistance:
  • Tire size (e.g., 245/35R19)
  • Rolling resistance coefficient (Crr): 0.01–0.025
  • Tire slip and grip modeling (μ-slip curve with temperature-dependent friction)
• Braking System:
  • Brake bias distribution (front/rear)
  • Thermal fade modeling (optional)

📊 Performance Analytics – Data-Driven Benchmarking

MotorSim 2 outputs scientifically accurate, repeatable performance metrics, validated against real-world test data and industry standards (SAE J2723, DIN 70021, etc.).

✅ Standard Acceleration Benchmarks (0–X km/h):

• 0–60 km/h
• 0–100 km/h
• 0–200 km/h
• 0–300 km/h (for high-performance vehicles)

✅ Top-Speed & Gear Analysis:

• Theoretical maximum velocity (with gear-limited and aerodynamic-limited calculations)
• Gear usage map: Which gear achieves peak speed?
• RPM at top speed and redline margin

✅ Quarter-Mile (402 m) Simulation:

• Real-time elapsed time (ET) and trap speed
• Ghost car comparison (save and overlay simulations)
• Launch optimization: Best launch RPM, wheel spin threshold, traction control tuning

✅ Custom Simulation Traces:

• Exportable time-series data (CSV/JSON):
  • Speed (km/h), RPM, gear, throttle %, torque, acceleration (g-force)
  • Aerodynamic drag (N), rolling resistance (N), drive wheel torque (Nm)
• Graphical analysis tools (built-in plots for torque vs. speed, g-force vs. time, etc.)

🎮 Interactive Simulation Environment – Immersive Engineering Lab

MotorSim 2 is not a video game — it’s a digital engineering lab for tuning and validation.

🖥️ Real-Time Instrumentation:

• Digital tachometer (RPM with redline warning)
• Speedometer (km/h with 0.1 km/h precision)
• G-force meter (longitudinal, lateral, vertical)
• Gear indicator with shift light simulation

🔁 Dynamic Controls:

• Manual transmission: Clutch pedal, gear shift knob
• Automatic transmission: Mode selector (Sport, Eco, Manual)
• Throttle/brake modulation (analog or PWM input simulation)

🔊 Procedurally Generated Engine Audio

• Algorithmic sound synthesis based on:
  • RPM, load, and intake/exhaust flow
  • Cylinder count, firing order, and exhaust system design
  • Realistic revving, backfire, and gear-shift noise

🏁 Quarter-Mile Drag Strip Visualization

• 3D-rendered track with:
  • Starting line (burnout paddle, line lock)
  • Timer (0.000s precision)
  • Ghost car overlay (compare up to 5 saved builds)
  • Surface type (asphalt, concrete, racing slicks)

📁 Save & Compare – Engineering Workflow Integration

• Save configurations as .motorsim files (encrypted, version-controlled)
• Compare multiple builds side-by-side:
  • Side-by-side ET and trap speed
  • Graphical overlay of acceleration curves
  • Delta analysis (performance gain/loss per modification)

🧪 Use Cases for MotorSim 2

📈 Accuracy & Validation

• Physics Engine: Custom-built, validated against SAE J606, J866, and ISO 9001 standards
• Units: Metric (SI) and imperial (optional toggle)
• Validation: Cross-checked with published data from Porsche, Tesla, Ford, and top drag racing teams

📞 System Requirements (Recommended)

• OS: Windows 10/11, macOS 12+, Ubuntu 22.04+
• CPU: Quad-core 3.0 GHz+
• GPU: Dedicated (NVIDIA/AMD, OpenGL 4.6+)
• RAM: 16 GB+
• Display: 1920×1080 minimum (supports 4K)

📦 Download & License

• Free Trial: Full features, 30-day limit
• Pro License: $99/year (unlimited simulations, export, updates)
• Enterprise License: Custom API access, batch processing, integration with CAD/CAE tools

✅ MotorSim 2: Where Engineering Meets Precision.
Not just a calculator — it’s your virtual dyno, test track, and tuning lab in one.

🔁 Ready to simulate your next performance upgrade?
Launch MotorSim 2 and see how small changes impact real-world performance — with scientific accuracy, every time.
